Model
TR608-YHT5

Item specifics

Power
AC220V/50HZ,
Name
wire stripping machine
Feature
Stable Performance
Warranty
1year
Contact
Lily 0086-13715588365

Review

Description

TR-608-YHT5 Multi-functional Intelligent Round Jacket Inside and Outside cable wire Stripping Machine
Power supply: AC220/110V 60HZ/50HZ, 850W
Display mode: 7-inch Chinese English switching touch screen
Size and weight: 560x460x400mm, 90kg
Outer diameter of processed round sheath: ￠ 2-12mm
Blade material: imported high-speed steel
Processing line cores: 2 cores, 3 cores, 4 cores, 5 cores
Maximum diameter of the catheter: ￠ 13
Air pressure: 0.8Mpa
Peeling accuracy: ± 0.2mm
Cutting length: maximum 100m
Warranty period: 3 years
Two peeling lengths: head half peeling (1-350mm) and tail half peeling (1-150mm)
Length of round sheath peeling: head peeling (1-210mm), tail peeling (1-110mm)
Wire stripping speed: 2500-3500 pieces/hour (L=300mm)
Drive mode: 8-wheel drive (silent hybrid stepper motor, advancing 0.1mm per step)
