TR-508-MAX1-6/NP 6-wheel 25 square wire stripping machine
- Model
- TR-508-MAX1-6/NP
Item specifics
- Power
- AC220V/50HZ,
- Name
- wire stripping machine
- Feature
- Stable Performance
- Warranty
- 1year
- Contact
- Lily 0086-13715588365
Review
Description
TR-508-MAX1-6/NP 6-wheel 25 square wire stripping machine
TR-508-MAX1-6/NP (6-wheel 25 square wire stripping machine)
(with positive and negative straightener, with NP as key panel)
Weight: 43KG
Dimensions: 470mm×515mm×345mm Power: 550W
Display mode: Chinese and English LCD liquid crystal display Cutting length: 0.1mm-10000mm
Stripping length: thread head 0-50mm, thread tail: 0-50mm
Cutting tolerance: within 0.002×L (L=cutting length)
Cross-sectional area of cutting wire core: 0.2-25mm2 BV single-strand wire cuts 6 square meters
The largest diameter of the catheter: ¢13
Middle peeling: 13 peeling
Tool material: high-quality imported high-speed steel
Stripping speed: 100mm length as unit: 3000-4000 wires/hour
Drive mode: six-wheel drive (silent hybrid stepper motor, each step advances 0.1mm)
Wire stripping speed: cutter speed and wire feeding speed can be adjusted separately: 0 is the slowest, 9 is the fastest
PRODUCT USEINTRODUCTION
Thefully automatic computerized wire stripping machine produced byourfactoryis widely used in wire harness processingin variousindustriessuch as wire harnesses, automotive electricalappliances, instruments andmeters, lamps, household appliances, etc., such as: single-stranded wire,multi-stranded wire, sheathed wire, etc.The processing methods are: cutting,strippinghead and tail, middle stripping, bending, twisting, etc. Themaximum processingcross-sectional area is 0.1-90mm2, and the maximumlength of the cutting section is 100 meters. The main function of themachine is to strip the plastic sheath and the metal core of the wire.
