TR608-SD/N Small four-wheeled short wire type cable wire stripping machine
TR608-SD/N Small four-wheeled short wire type cable wire stripping machine
TR608-SD/N Small four-wheeled short wire type cable wire stripping machine
TR608-SD/N Small four-wheeled short wire type cable wire stripping machine
TR608-SD/N Small four-wheeled short wire type cable wire stripping machine
TR608-SD/N Small four-wheeled short wire type cable wire stripping machine

TR608-SD/N Small four-wheeled short wire type cable wire stripping machine

Model
TR608-SD/N

Item specifics

Power
AC220/110V/60HZ/50HZ
Name
wire stripping machine
Feature
Stable Performance
Warranty
3year
Contact
CoCo +86 18666170785

Review

Description

TR608-SD/N Small four-wheeled short wire type cable wire stripping machine
Size:460x470x325mm
Display mode: Chinese and English switching LCD
Cutting length:1~10000mm
Cutting tolerance: earth (0.002xL) mm
Suitable for stripping wire: PVC, Teflon, glass wire
Stripping speed: 5000-10000 pcs/hour (L=100mm)
Power supply: AC220/110V 50/60Hz, rated 300W.
Stripping length: wire head 0-30mm, wire tail 0-15mm
Maximum diameter of conduit: ¢6
Cutting core cross-section: 0.1~4mm²
Intermediate stripping:13 stripping
Warranty:3 years
Driving mode: four-wheel drive (silent hybrid stepping motor, each step forward 0.1mm)
