TR-388DZ Fully automatic double-head crimping enadouble-head inserting shellsingle-head threading hydrant machine
- Model
- TR-388DZ
Item specifics
- Power
- AC220V/50HZ
- Scope of processing
- 0.35-2 mm²
- Feature
- Stable Performance
- Warranty
- 1year
Review
Description
TR-388DZ Fully automatic double-head crimping enddouble-head inserting shellsingle-head threading hydrant machine
Power supply : 220V 4900W
Size&weight : 1600mm*2200mm*2050mm,Approx. 1000kg
Scope of processing : 0.35-2 mm² (to be confirmed by sample)
Wire processing length : 140mm-600mm (length accuracy: 0.003*L length)
Strip length : 0--10mm at both ends (special sizes can be altered)
Detection function : Visual Inspection, Missing Line Inspection, Air Pressure Inspection,
Take-up Inspection, Draw Inspection, Pressure Inspection
Air pressure : 4.5--6kgf (dry air)
Speed : 6 seconds/root (the actual speed of customised parts is finalis
Multi-functional:
① terminal crimping bad reset will cut off the terminal and then the next step in the process;
② wire shortage and knot alarm;
③ can be set to wear shells through the bolt position;
④ can be worn at one end of a kind of rubber shells, the other end of the other end to wear the same shells of two.
High quality:
① equipment using servo plus imported slide rail imported high-precision structure configuration, to ensure the stability and durability of the equipment.
② High speed - servo length measurement module, traverse using a screw linkage, to achieve the perfect unity of precision and speed.
