TR-SC26 Semi-auto Rechargeable Lithium Battery Electric Handheld Tape Wrapping Machine with Fixed Base for Wire Harness

Tape dispenser (without battery) size&weight:250x300x280mm,approx. 4kg

Battery (without tape dispenser) norm:6000mh Li-ion battery 10-21V-4.0A;weight:Approx. 0.6kg;Battery Continuous Discharge Time:Approx. 5-6 hours

Winding speed

first gear:150 rpm;second gear:200 rpm;

third gear:350 rpm;fourth gear:500 rpm

Adhesive tape

widths:10-25mm;

OD:Less than 110mm;

inner circle:Standard 38mm, other specifications can be customised;

types:PVC, nylon, cloth-based, etc.

Wrapable Wire Diameter:3-25mm

This machine is small and flexible. The weight of the machine is only 1.65kg, and the machine has a hooked rope, which can be hung in the air to share and bear part of the weight, and the open design can start wrapping from any position of the wire harness, and it's easy to skip the branches, it is suitable for tape wrapping of wire harnesses with branches, Of ten used for wire harness assembly board to assemble wire harness.

Advantage

1. Can work with many kinds of material tapes

2. Lightweight, easy to move and not easy to feel tired, high efficiency

3. Simple operation, operators only need simple exercises

4. Easily adjust the distance of the tape and overlap, reducing the waste of tape

5. After cutting the tape, the tool automatically jumps to the next position for the next preparation, no additional process

6. The finished products have appropriate tension and no wrinkle
